Prologue
Table of contents
Ontologies (1):
Classes (14):
Atlas , Editor , Etymon , Geographical Point , Image , Informer , Interpretation , Inventory entry , Lemma , Map , Map Title , Notion , Response , Survey point
Properties (65):
age , atlas Name , begin Date , booklet , contains , contextualized Title , country , date , description , designating , end Date , etymon Comment , etymons , few Etymon , few Etymon Language , few Etymon Reference , few Etymon Signified , for Survey Point , gave Response , gender , grammatical Nature , ground , has Editor , has Image , has Informer , has Interpretation , has Inventory Entry , has Notion , has Response , has Survey Point , hasTitle , height , identifier , informant Comment , informant Gender , interpretation Comment , interpretation Date , is Double Page , is Inventory Entry Of , is Notion Of , is Response Of , is Survey Point OF , latitude , lemma Comment , lemmas , lemmatized Response , longitude , map Identifer , map Index , map Type , more Information , number , page Number , phonetic Transcription , place Name , response Type , rousselot Phonetic Form , sp Identifier , specific Ground , title , title , uncertainty , width , x Viewport , y View Port
Diagramme de l'ontologie
ontology (Ontology)
L'ontologie qui suit présente les différentes classes et propriétés du modèle de données de l'application Cartodialect.
Definition
The URI of this ontology is http://purl.org/fr/eclats/ontology
In use
Classes
Atlas , Editor , Etymon , Geographical Point , Image , Informer , Interpretation , Inventory entry , Lemma , Map , Map Title , Notion , Response , Survey point
Atlas (OWL Class)
Un atlas linguistique regroupe un ensemble de cartes
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#Atlas
In use
| This class is used in | atlas Name begin Date end Date has Image |
Etymon (OWL Class)
Etymon d'un lemme (sa racine étymologique)
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#Etymon
In use
| This class is used in | etymon Comment few Etymon few Etymon Language few Etymon Reference few Etymon Signified uncertainty |
Geographical Point (OWL Class)
{{No description available}}
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#GeographicalPoint
| This class is a sub class of | http://www.opengis.net/ont/sf#Point |
Image (OWL Class)
Version numérique d'une page de l'Atlas
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#Image
In use
| This class is used in | booklet contains has Image height is Double Page page Number width |
Informer (OWL Class)
L’entité qui a fourni la réponse.
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#Informer
In use
| This class is used in | age gave Response has Informer informant Comment informant Gender |
Inventory entry (OWL Class)
Une entrée d'inventaire fait l'assocition entre - une carte - un point d'enquête - la ou les réponse(s) apportée(s) sur cette carte
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#InventoryEntry
In use
| This class is used in | for Survey Point has Inventory Entry has Response has Survey Point is Inventory Entry Of is Response Of is Survey Point OF sp Identifier x Viewport y View Port |
Lemma (OWL Class)
"Unité autonome constituante du lexique d'une langue". Peut correspondre à une réponse ou un partie d'une réponse.
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#Lemma
In use
| This class is used in | etymons gender grammatical Nature lemma Comment lemmas number |
Map (OWL Class)
Une carte est associée à l'image qui la contient. Une carte porte sur une ou plusieurs notions linguistiques ou bien une notion linguistique sous plusieurs formes. L’ensemble des notions (avec leurs éventuelles formes) d'une carte est exprimé par ce que nous nommerons l'intitulé (MapTitle) de la carte.
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#Map
In use
| This class is used in | contains has Inventory Entry hasTitle is Inventory Entry Of map Identifer map Index map Type |
Map Title (OWL Class)
L'intitulé d'une carte linguistique correspond au titre de la carte. Dans le cas de l'ALF il exprime l’ensemble des notions (avec leurs éventuelles formes) interrogées par l'enquêteur pour une carte. C'est le texte en majuscule et en gras, défini , en général, dans le coin supérieur gauche de celle-ci, par exemple la carte n° 659 a pour intitulé « À GROSSES GOUTTES ».
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#MapTitle
In use
| This class is used in | contextualized Title has Notion hasTitle is Notion Of title |
Notion (OWL Class)
Une Notion est un concept attaché à l'un des mots de l'intitulé d'une carte. A un même mot peuvent correspondre une ou plusieurs notions. Ce qu'en lexicologie on nomme le champ sémantique d'un mot: l'ensemble des sens disponibles de ce mot selon le contexte (ex : Fraise : le fruit / celle du dentiste / cols des notables à l'époque de Henri IV).
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#Notion
In use
| This class is used in | has Notion is Notion Of |
Response (OWL Class)
Une réponse donne la forme phonetique qui a été inventoriée dans l’atlas en un point d’enquête donné. On peut ou non connaitre la nature de l’informateur qui a donné cette réponse.
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#Response
In use
| This class is used in | has Interpretation has Response is Response Of rousselot Phonetic Form |
Survey point (OWL Class)
Un point d’enquête est un lieu géographique.
Definition
The URI of this class is http://purl.org/fr/eclats/ontology#SurveyPoint
| This class is a sub class of | http://www.opengis.net/ont/geosparql#Feature |
In use
| This class is used in | country for Survey Point gave Response has Informer has Survey Point is Survey Point OF latitude longitude place Name |
Properties
age , atlas Name , begin Date , booklet , contains , contextualized Title , country , date , description , designating , end Date , etymon Comment , etymons , few Etymon , few Etymon Language , few Etymon Reference , few Etymon Signified , for Survey Point , gave Response , gender , grammatical Nature , ground , has Editor , has Image , has Informer , has Interpretation , has Inventory Entry , has Notion , has Response , has Survey Point , hasTitle , height , identifier , informant Comment , informant Gender , interpretation Comment , interpretation Date , is Double Page , is Inventory Entry Of , is Notion Of , is Response Of , is Survey Point OF , latitude , lemma Comment , lemmas , lemmatized Response , longitude , map Identifer , map Index , map Type , more Information , number , page Number , phonetic Transcription , place Name , response Type , rousselot Phonetic Form , sp Identifier , specific Ground , title , title , uncertainty , width , x Viewport , y View Port
atlas Name (Property)
Le nom de l'Atlas numérisé (Atlas Linguistique de France (ALF), Atlas des Alpes et du Jura (ALJA) ...)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#atlasName
This property is a data property.
| The domain of this property is | Atlas |
booklet (Property)
définit le numéro du fascicule duquel est issue une image de carte
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#booklet
This property is a data property.
| The domain of this property is | Image |
| The range of this property is | xsd:string |
contextualized Title (Property)
phrase qui permet de contextualiser l'intitulé (exemple pour la carte 659 "à grosse gouttes (je sue -))
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#contextualizedTitle
This property is a data property.
| The domain of this property is | Map Title |
| The range of this property is | xsd:string |
country (Property)
nom du pays où se trouve le point d'enquête
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#country
This property is a data property.
| The domain of this property is | Survey point |
| The range of this property is | xsd:string |
date (Property)
{{No description available}}
Definition
The URI of this property is http://purl.org/dc/terms/date
This property is a data property.
| This property is a super property of | begin Date end Date |
description (Property)
{{No description available}}
Definition
The URI of this property is http://purl.org/dc/terms/description
This property is a annotation property.
In use
This property has 5 occurrences
designating (Property)
Le désigant (ex "plante dont les feuilles sont trouées" pour millepertuis)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#designating
This property is a data property.
| The domain of this property is | Interpretation |
| The range of this property is | xsd:string |
etymon Comment (Property)
le commentaire libre associé à l'étymon
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#etymonComment
This property is a data property.
| The domain of this property is | Etymon |
| The range of this property is | xsd:string |
etymons (Property)
liste des étymons composant le lemme
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#etymons
This property is a object property.
| The domain of this property is | Lemma |
few Etymon (Property)
l'étymon dans le FEW
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#fewEtymon
This property is a data property.
| The domain of this property is | Etymon |
| The range of this property is | xsd:string |
few Etymon Language (Property)
Lange d'origine de l'étymon (LATIN, ANGLAIS, BRETON ....)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#fewEtymonLanguage
This property is a data property.
| The domain of this property is | Etymon |
| The range of this property is | xsd:string |
few Etymon Reference (Property)
réfrence (vol, page....) de l'étymon dans FEW
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#fewEtymonReference
This property is a data property.
| The domain of this property is | Etymon |
| The range of this property is | xsd:string |
few Etymon Signified (Property)
Le signifié de l'étymon: c’est le sens de l’étymon donné par le FEW
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#fewEtymonSignified
This property is a data property.
| The domain of this property is | Etymon |
| The range of this property is | xsd:string |
for Survey Point (Property)
Chaque entrée d'inventaire représente un point d'enquête dans une image
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#forSurveyPoint
This property is a object property.
| The domain of this property is | Inventory entry |
| The range of this property is | Survey point |
gave Response (Property)
la réponse à une question posée à un informateur
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#gaveResponse
This property is a inverse functional, object property.
| This property is a inverse property of | has Informer |
| The domain of this property is | Informer |
| The range of this property is | Survey point |
gender (Property)
genre du lemme (feminin, masculin)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#gender
This property is a data property.
| The domain of this property is | Lemma |
| The range of this property is | xsd:string |
grammatical Nature (Property)
nature gramaticale du lemme (Adjectif, adverbe, ...) . Pour le moment traité avec des strings, voir si on peut pas utiliser une énumération
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#grammaticalNature
This property is a data property.
| The domain of this property is | Lemma |
| The range of this property is | xsd:string |
ground (Property)
Le motif général de la réponse (ex "aspect" pour le Millepertuis)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#ground
This property is a data property.
| The domain of this property is | Interpretation |
| The range of this property is | xsd:string |
has Editor (Property)
L'éditeur de l'interprétation
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#hasEditor
This property is a data property.
| The domain of this property is | Interpretation |
has Informer (Property)
un point d'enquête est associé à un ou plusieurs informateurs
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#hasInformer
This property is a object property.
| This property is a inverse property of | gave Response |
| The domain of this property is | Survey point |
| The range of this property is | Informer |
has Interpretation (Property)
une réponses peut avoir une ou plusieurs interprétations
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#hasInterpretation
This property is a object property.
| The domain of this property is | Response |
| The range of this property is | Interpretation |
has Inventory Entry (Property)
une carte est constituée de une ou plusieurs entrées d'inventaires
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#hasInventoryEntry
This property is a object property.
| This property is a inverse property of | is Inventory Entry Of |
| The domain of this property is | Map |
| The range of this property is | Inventory entry |
has Notion (Property)
un titre peut être constitué d'une ou plusieurs notions
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#hasNotion
This property is a functional, object property.
| This property is a inverse property of | is Notion Of |
| The domain of this property is | Map Title |
| The range of this property is | Notion |
has Response (Property)
une entrée d'inventaires peut avoir une ou plusieurs réponse. Par exemple, le point n°407 de la carte Mille-Pertuis possède deux réponse (mille-pertuis et mille poires cuites).
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#hasResponse
This property is a object property.
| This property is a inverse property of | is Response Of |
| The domain of this property is | Inventory entry |
| The range of this property is | Response |
has Survey Point (Property)
une ou plusieurs entrées d'inventaire correspondent à un point d'enquête.
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#hasSurveyPoint
This property is a functional, object property.
| This property is a inverse property of | is Survey Point OF |
| The domain of this property is | Inventory entry |
| The range of this property is | Survey point |
identifier (Property)
{{No description available}}
Definition
The URI of this property is http://purl.org/dc/terms/identifier
This property is a data property.
informant Comment (Property)
C'est le commentaire associé à un informateur. On trouve cette information dans la notice de l'ALF (par exemple: 'linformateur est une jeune fille, ou encore: c'est un dentiste ...)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#informantComment
This property is a data property.
| The domain of this property is | Informer |
| The range of this property is | xsd:string |
informant Gender (Property)
Le gendre de l'informateur, FEMININ ou MASCULIN
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#informantGender
This property is a data property.
| The domain of this property is | Informer |
| The range of this property is | xsd:string |
interpretation Comment (Property)
commentaire libre associé à l'interprétation
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#interpretationComment
This property is a data property.
| The domain of this property is | Interpretation |
| The range of this property is | xsd:string |
interpretation Date (Property)
La date à laquelle la réponse a été créée (date système)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#interpretationDate
This property is a data property.
| The domain of this property is | Interpretation |
| The range of this property is | xsd:long |
is Double Page (Property)
true si l'image contient la numérisation de deux pages de l'atlas
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#isDoublePage
This property is a data property.
| The domain of this property is | Image |
| The range of this property is | xsd:boolean |
is Inventory Entry Of (Property)
une carte est constituée de une ou plusieurs entrées d'inventaires
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#isInventoryEntryOf
This property is a functional, object property.
| This property is a inverse property of | has Inventory Entry |
| The domain of this property is | Inventory entry |
| The range of this property is | Map |
is Notion Of (Property)
une carte est constituée de une ou plusieurs entrées d'inventaires
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#isNotionOf
This property is a object property.
| This property is a inverse property of | has Notion |
| The domain of this property is | Notion |
| The range of this property is | Map Title |
is Response Of (Property)
une entrée d'inventaires peut avoir une ou plusieurs réponse. Par exemple, le point n°407 de la carte Mille-Pertuis possède deux réponse (mille-pertuis et mille poires cuites).
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#isResponseOf
This property is a functional, object property.
| This property is a inverse property of | has Response |
| The domain of this property is | Response |
| The range of this property is | Inventory entry |
is Survey Point OF (Property)
une ou plusieurs entrées d'inventaire correspondent à un point d'enquête.
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#isSurveyPointOF
This property is a object property.
| This property is a inverse property of | has Survey Point |
| The domain of this property is | Survey point |
| The range of this property is | Inventory entry |
latitude (Property)
La latitude associée au point d'enquête
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#latitude
This property is a data property.
| The domain of this property is | Survey point |
| The range of this property is | xsd:double |
lemma Comment (Property)
commentaire libre associé au lemme
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#lemmaComment
This property is a data property.
| The domain of this property is | Lemma |
| The range of this property is | xsd:string |
lemmas (Property)
liste des lemmes de la réponse lemmatisée de l'interprétration
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#lemmas
This property is a functional, object property.
| The domain of this property is | Interpretation |
| The range of this property is | Lemma |
lemmatized Response (Property)
réponse lémmatisée
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#lemmatizedResponse
This property is a data property.
| The domain of this property is | Interpretation |
| The range of this property is | xsd:long |
longitude (Property)
la longitude associée au point d'enquête
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#longitude
This property is a data property.
| The domain of this property is | Survey point |
| The range of this property is | xsd:double |
map Identifer (Property)
Identifant d'une carte son numéro ex: 859 pour la carte" millepertuis" ou 1349A et 1349B pour les deux demi cartes "VACHE- VACHES"
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#mapIdentifer
This property is a data property.
| The domain of this property is | Map |
| The range of this property is | xsd:string |
map Index (Property)
L'ordre d'apparition de la carte dans l'ordre de l'atlas (exemple la carte 10A a comme index 10 et la carte 10B a comme index 11, et la carte 11 a comme index 12, etc...)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#mapIndex
This property is a data property.
| The domain of this property is | Map |
| The range of this property is | xsd:integer |
map Type (Property)
Le type de carte indique si la carte est une carte complète (elle couvre tous les points d'enquêtes) ou partielle (elle ne couvre qu'une région du territoire enquêté). Dans l'ALF on distingue les types de cartes suivants: (COMPLETE, EST, OUEST, NORD, SUD, NORD-EST, NORD-OUEST, SUD-EST, SUD-OUEST)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#mapType
This property is a data property.
| The domain of this property is | Map |
| The range of this property is | xsd:string |
number (Property)
nombre du lemme (SINGULIER, PLURIEL)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#number
This property is a data property.
| The domain of this property is | Lemma |
| The range of this property is | xsd:string |
page Number (Property)
Numero de la page
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#pageNumber
This property is a data property.
| The domain of this property is | Image |
| The range of this property is | xsd:integer |
phonetic Transcription (Property)
transcription phonétique en API
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#phoneticTranscription
This property is a data property.
| The domain of this property is | Interpretation |
| The range of this property is | xsd:string |
place Name (Property)
Nom du lieu enquêté
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#placeName
This property is a data property.
| The domain of this property is | Survey point |
| The range of this property is | xsd:string |
response Type (Property)
Type de la réponse. L'annotateur à le choix entre "Phrase" "Syntagme" ou "Lemme"
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#responseType
This property is a data property.
| The domain of this property is | Interpretation |
| The range of this property is | xsd:string |
rousselot Phonetic Form (Property)
Forme phoétique en alphabet Rousselot-Gilliéron
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#rousselotPhoneticForm
This property is a data property.
| The domain of this property is | Response |
| The range of this property is | xsd:string |
sp Identifier (Property)
identifiant du point d'enquête (numéro dans l'ALF le numéro du point d'enquête)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#spIdentifier
This property is a data property.
| The domain of this property is | Inventory entry |
| The range of this property is | xsd:string |
specific Ground (Property)
Motif specifique de l'interprétation (ex "aspect troué des feuilles" pour le millepertuis)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#specificGround
This property is a data property.
| The domain of this property is | Interpretation |
| The range of this property is | xsd:string |
title (Property)
L'intitulé de la carte (exemple CHAMPIGNON carte 227 ou A GROSSES GOUTTES, carte 659)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#title
This property is a data property.
| The domain of this property is | Map Title |
| The range of this property is | xsd:string |
title (Property)
{{No description available}}
Definition
The URI of this property is http://purl.org/dc/terms/title
This property is a data property.
uncertainty (Property)
niveau de confiance associé à l'étymon choisi (certain, incertain, très incertain)
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#uncertainty
This property is a data property.
| The domain of this property is | Etymon |
| The range of this property is | xsd:string |
x Viewport (Property)
abscisse (en coordonnées viewport) de l'entrée d'inventairte dans l'image de la carte
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#xViewport
This property is a data property.
| The domain of this property is | Inventory entry |
| The range of this property is | xsd:double |
y View Port (Property)
ordonnée (en coordonnées viewport) de l'entrée d'inventairte dans l'image de la carte
Definition
The URI of this property is http://purl.org/fr/eclats/ontology#yViewPort
This property is a data property.
| The domain of this property is | Inventory entry |
| The range of this property is | xsd:double |
Glossary
- Atlas
- Atlas
- Editor
- Editor
- Etymon
- Etymon
- Geographical Point
- Geographical Point
- Image
- Image
- Informer
- Informer
- Interpretation
- Interpretation
- Inventory entry
- Inventory entry
- Lemma
- Lemma
- Map
- Map
- Map Title
- Map Title
- Notion
- Notion
- Response
- Response
- Survey point
- Survey point
- hasTitle
- hasTitle
Go to top
Ontologies
Classes
Properties
Expand/Collapse all
Back to form
Help
